Jumbo 17
Materials:
Aluminium support profile with scraper bar. Roughened rubber strips with integrated nylon as a scraper.
Colours:
Rubber strips in 6 colours available.
Features:
Can be used indoors and outdoors. Extremely durable. Permits traffic from shopping carts, hospital beds, light hand trucks up to 1000 kg, etc. Good scraping action and high drying rate from roughened surface. Cannot be rolled up. Reversible. Mat must lie flat and completely flush with the surface.
Dimensions:
Mat height: 17 mm
Profile length: Max. 3.00 m
Walking depth: Max. 0.55 m
Large mats must also be made in two or more parts.
Weight:
Approx. 14 kg/m²
Available Colors
Types
| Part no. | Product description | Approx. mat height | Compatible angle frame inside height |
|---|---|---|---|
| 20 200 | Hagomat Jumbo 17 solid design | 17 mm | 17 mm |
Tender specification
HAGOMAT Jumbo 17, Part no 20 200 Aluminium support profile with scraper bar. Roughened solid rubber strips with integrated nylon. Colour . . . . . . . . . . . . Deliver and install.
